Poles

PL series

Circular pole for LOGIKA and Q QUADRO

PL pole for public lighting in steel with a circular section made in a single section. The pole is equipped with a drawn aluminium bracket for installing luminaires from the LOGIKA and Q QUADRO series. The PL series public lighting poles are available in 1, 2, 3 bracket versions.

Go to download

Circular section Made in Italy

Circular section

Made in Italy

Characteristics

PL pole for public lighting in steel with a circular section made in a single section. The pole is equipped with a drawn aluminium bracket for installing luminaires from the LOGIKA and Q QUADRO series. The PL series are available in 1, 2, 3 bracket versions. Cable entry slot and slot for terminal block with cut edge finish also suitable for the application of a flush mounted cover.

Four available heights

PL 5

Height 5000 mm
Single stroke diameter Ø 102 mm
In-ground 500 mm

PL 6

Height 6000 mm
Single stroke diameter Ø 127 mm
In-ground 800 mm

PL 7

Height 7000 mm
Single stroke diameter Ø 127 mm
In-ground 800 mm

PL 8

Height 8000 mm
Single stroke diameter Ø 127 mm
In-ground 800 mm

Available colours

Hot dip galvanizing according to UNI EN ISO 1461 and subsequent brushing to ensure a perfect surface finish. Polyester powder coating.

Graphite

Code 01

Black

Code 02

Silver

Code 03

Sand

Code 04

RAL colours

On request

Reduce the operative costs

Improve the performance

Assure safety

LED lamps compatible with the PL pole

The PL pole for public lighting can only be combined with LOGIKA and Q-QUADRO

LOGIKA

Q QUADRO

How AEC assures visual comfort

Click here

The importance of light uniformity

Click here

How to enhance historical places

Click here

Download

Download the technical documentation of PL lighting pole.

Product sheet

PL lighting pole

Download

2d dwg drawing

PL lighting pole

The file is reserved for registered users

Mounting instructions

BA pattern decorative bases

The file is reserved for registered users

PL series

Circular pole for LOGIKA and Q QUADRO

Characteristics

PL lighting pole

Ideal for street and urban lighting

PL 5

PL 6

PL 7

PL 8

Available colours

Hot dip galvanizing according to UNI EN ISO 1461 and subsequent brushing to ensure a perfect surface finish. Polyester powder coating.

Graphite

Code 01

Black

Code 02

Silver

Code 03

Sand

Code 04

RAL colours

On request

Reduce the operative costs

Improve the performance

Assure safety

LED lamps compatible with the PL pole

The PL pole for public lighting can only be combined with LOGIKA and Q-QUADRO

LOGIKA

Q QUADRO

How AEC assures visual comfort

The importance of light uniformity

How to enhance historical places

Download

Download the technical documentation of PL lighting pole.

Product sheet

2d dwg drawing

Mounting instructions
