Design Series – Cylindrical PE Pole with bracket

Cylindrical pole with shelf

Circular section steel pole made up of two sections that can be assembled with a semi-curved Ø60 outreach and conical end.

Go to downloads
Circular section Made in Italy

Circular section steel pole made up of two sections that can be assembled with a semi-curved Ø60 outreach and conical end.

Characteristics

Circular section steel pole made up of two sections that can be assembled with a semi-curved Ø60 outreach and conical end. Cable entry slot and terminal block slot with cut edge finish also suitable for the application of a recessed door flush with the pole.

Design Series public lighting pole with bracket

Ideal for street and urban lighting

Download DWG
Four heights available

6000

Light point height 6000 mm
Tip length 850 mm
Dimension at the base Ø 127 mm
Arm diameter Ø 76 mm
Arm protrusion 800 mm
Attachment shank Ø 60 mm
Built 800 mm

7000

Light point height 7000 mm
Tip length 850 mm
Dimension at the base Ø 127 mm
Arm diameter Ø 76 mm
Arm protrusion 800 mm
Attachment shank Ø 60 mm
Built 800 mm

8000

Light point height 8000 mm
Tip length 850 mm
Dimension at the base Ø 127 mm
Arm diameter Ø 76 mm
Arm protrusion 1000 mm
Attachment shank Ø 60 mm
Embedment 800 mm

9000

Light point height 9000 mm
Tip length 850 mm
Dimension at the base Ø 139 mm
Arm diameter Ø 76 mm
Arm protrusion 1000 mm
Attachment shank Ø 60 mm
Embedment 800 mm

Colors available

Hot galvanizing according to UNI EN ISO 1461 and subsequent brushing to guarantee a perfect surface finish. Polyester powder coating.

Graphite

Code 01

Black

Code 02

Silver

Code 03

Sand

Code 04

Colore RAL

RAL Colorurs

On request

Products compatible with the PE cylindrical pole with bracket

Standard connection spigot for devices equipped with Ø 60 mm connection

COMPASS

ITALO 2 URBAN

Q-DROME

STYLO

ITALO
